L型横式单位散热器
L型横式单位散热器本散热器系是由外径φ6毫米，壁厚1毫米紫铜管及10×0.2毫米紫铜带构成，片距为3.2毫米，后面由三叶轴流风扇通风。同一型号暖风机风扇的转速有三种，是用双速电动而获得，其风速、流量因不同转速而亦不相同。表列静度是散热器在适用时发出的噪音量（DB）的大小，噪音越小，则静度愈高。“A”级静度*优，“B”级则次，“C”级静度再次之，“D”级静度适用工厂、仓库等，噪音量在80-85.5分贝。 横式单位散热器型号说明 本散热器是用三组数字字母表示。第一组 表示散热量千位数（大卡/时）第二组 字母表示导风叶的型式第三组 表示散热器排管单管（一排）、双排（二排） 例如：4L2型即表示该散热器具有4000千卡/时的散热量，导风叶为“L”型，散热排管为双排（二排）L型横式单位散热器基本参数见表L型横式单位散热器补充型号基本参数见表
L型横式单位散热器基本参数表（以蒸汽为热源）三相 50周/秒 交流电动机 或两速 蒸汽压力＝0.15Kg/cm2 进风温度＝15℃
型号每分钟转数快慢散热量大卡/小时风量公尺3/小时在20℃风量公尺3/小时在t℃出风温度t℃出风速度公尺/秒静度配用电机千瓦冷凝水公斤/小时基本型4L29607204130340061946565749739411.551.18A0.12/0.09879L29607208940730062647071654665691.711.30A0.12/0.09171411L21425960111008940931626104471757652.481.71A0.12/0.09211713L214259601265095201125756125385554592.982.03A0.12/0.09241815L2142596015120119201225827141095158662.331.58A0.12/0.09292318L214259601826013610158010621766120255602.931.99BA0.12/0.09352621L214259602115016550201213582222152852583.682.53CB0.12/0.09403129L29607202872023120249018702774210555582.932.22BA0.12/0.09544435L214259603540025550326221623620237053573.822.50CB0.12/0.09664853L214259605318040700535036205870401050554.853.30CB0.25/0.181007665L214259606500047820603240626662455053534.002.73CB0.25/0.181229071L214259607150054400713847817860535051554.703.20CB0.4/0.2513410288L214259608862065700828055859210626253574.072.78DC0.4/0.2516712399L21425960997007610010150683511125761049544.942.38DC1.1/0.55186143补充型号6L19607205740486268351374056146481.771.33A0.12/0.0912108L11425960301254401016683109274043462.591.77A0.12/0.0915129L11425960922069001211823130088842443.082.11A0.12/0.09181311L114259601122590161293830142097245512.321.61A0.12/0.09211713L11425960131609970171511531835124842453.032.07BA0.12/0.09251916L114259601656012660232015642480168040434.122.78CB0.12/0.09312419L19607201935016320270220302880218240433.052.30BA0.12/0.09363123L114259602340018470356023923770257238433.972.71CA0.12/0.09443533L114259603335026950577438906062412535395.013.42CB0.25/0.18635141L114259604140032880626242206620453538423.962.72CB0.25/0.18776244L114259604442036200743849847820532036404.683.18DC0.4/0.25836753L114259605325041600879059259262630036404.112.80DC0.4/0.251007859L1142596059440467701071072151120764035384.963.40DC1.1/0.5511188
